Name: WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK8010-19
Price: 42.00 USD
Availability: InStock

Evde > Ürünler > Su Seviye Transmitteri >

WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well

19mm submersible water level sensor

deep well water level transmitter

small diameter borehole sensor

Menşe yeri:

Anhui, Çin

Marka adı:

WNK

Model numarası:

WNK8010-19

Bizimle İletişim

Bir İndirim İste

Ürün Ayrıntıları

Garanti:

1 yıl

Özelleştirilmiş Destek:

OEM, ODM

Basınç aralığı::

0 ... 2 ~ 200 metre

Çıktı:

4-20mA, 0-5V, 1-5V, 0.5-4.5V, 0-10V

Kesinlik:

%0.2 FS,%0.5 FS,

Güç kaynağı:

12~36Vdc

Koruma sınıfı:

IP68

Başvuru:

Yağmur suyu, içme suyu, atık su, kanalizasyon, deniz suyu

Konut malzemesi:

304SS, 316L

Çalışma sıcaklığı::

-40~85 ℃

Tip:

Ölçmek

OEM hizmeti:

OEM, ODM, özelleştirme mevcut

Liman:

Şanghay/Ningbo

Vurgulamak:

19mm submersible water level sensor

deep well water level transmitter

small diameter borehole sensor

Ödeme ve Nakliye Şartları

Min sipariş miktarı

1 adet

Fiyat

$35.00 - $50.00/Pieces

Ambalaj bilgileri

Her biri tek tek bir kartona, köpüklü koruma olarak ayarlandı. Sonra Usta Karton'a

Teslim süresi

5-8 iş günü

Ödeme koşulları

T/T, Western Union, MoneyGram, PayPal

Yetenek temini

2000 Parça/Ayda Parça Basınç Sensörü

İlgili Ürünler

video

WNK ATEX Explosion Proof LCD Display Liquid Level Sensor With 4-20mA for Water Tank

En İyi Fiyatı Alın

video

WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well

En İyi Fiyatı Alın

video

WNK Submersible Hydrostatic Water Level Sensor Probe for River Tank Liquid Level Transmission Pressure Transmitter

En İyi Fiyatı Alın

video

316L Stainless Steel 4-20mA RS485 1-10V Liquid Level Transmitter Submersible Water Diesel Fuel Tank Level Sensors

En İyi Fiyatı Alın

Bizimle İletişim

Şimdi iletişime geçin

Ürün Tanımı

Product Description

Output	4-20mA, 0-5V, 1-5V, customization
Measured Range	0-0.5~200mH2O
Max overload	150% of sensor range
Pressure Type	Gage,Absolute
Accuracy	±0.2% FS/year
Long Term Stability	±0.25% FS/year
Housing Material	Stainless steel
Cable Material	Polyvinyl Fluoride, PTFE
Power supply	24V DC
Operating Temperature	-30~85℃
Compensation Temperature	-20~70℃
Protection Class	IP68

WNK8010-19 deep well water level sensor has high accuracy, small volume,stability,plus resistance to abrasion,oil,acid&alkali and high intensity gas lead cable ensured that it can meet the different occasions measurement requirements.

no-polarity two wire current output.

♦ It is widely used in well, standpipe, borewell, sewage, river and lakes treatment as well as channel, large rivers, l reservoirs and coastline monitoring.

♦ This product has got intrinsic safety certification,explosion proof certification and CE certification.

Applications

• Water tank level measurement and control.
• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).
• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.
• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)

Features
• Adopting diffusion silicon oil-filled sensor
• Max measure range up to 200 meters or more
• High Stability, provide 0.1, 0.2, 0.5 accuracy for option
• Factory direct price

Size/Principle
